RF Transmitter Receiver Module 315MHz Wireless Link Kit For Arduino

Description :

The RF Transmitter-Receiver Module Kit at 315MHz is a wireless communication module designed for simple and cost-effective data transmission between devices. It is commonly used with Arduino and other microcontrollers for applications such as remote control systems, wireless data transfer, and communication between electronic devices. Here are some key features and information about the RF Transmitter-Receiver Module Kit:

Pin Configuration :

The RF Transmitter and Receiver modules typically have the following pin configuration:

RF Transmitter Module :

• VCC: Power supply (e.g., 5V)
• GND: Ground
• DATA (or DATA IN): Data input (connects to a digital output pin on a microcontroller)

RF Receiver Module :

• VCC: Power supply (e.g., 5V)
• GND: Ground
• DATA (or DATA OUT): Data output (connects to a digital input pin on a microcontroller)

Wiring (Arduino) :

Here's a basic wiring example for connecting the RF Transmitter and Receiver modules to an Arduino:

RF Transmitter Module :

RF Receiver Module:

Technical Specification :

Package Includes :

• 1 x RF Transmitter Receiver Module 315MHz Wireless Link Kit.
