Raspberry Pi 3 Model B+
Raspberry Pi 3 Model B+
Raspberry Pi 3 Model B+
Raspberry Pi 3 Model B+
Anu Electronics

Raspberry Pi 3 Model B+

Product SKU: RS0000007
Available:
Only 5 items in stock
5 items in stock
In stock
Pre-order
Out of stock
Rs. 3,699.00
Rs. 3,800.00
Want it delivered by
  • Description

Description :

The Raspberry Pi 3 Model B+ is the latest product in the Raspberry Pi 3 range, boasting a 64-bit quad-core processor running at 1.4GHz, dual-band 2.4GHz, and 5GHz wireless LAN, Bluetooth 4.2/BLE, faster Ethernet, and PoE capability via a separate PoE HAT.
The secret sauce that makes this computer so small and powerful is the Broadcom BCM2837, an ARM Cortex-A53 64-bit Quad-Core Processor System-on-Chip operating at 1.4GHz. The GPU provides OpenGL ES 2.0, hardware-accelerated OpenVG and 1080p30 H.264 high-profile decode. It is capable of 1Gpixel/s, 1.5Gtexel/s or 24 GFLOPs of a general-purpose computer. What does that all mean? It means that if you plug the Raspberry Pi 3 B+ into your HDTV, you could watch Blu-ray quality video, using H.264 at 40MBits/s.
The Raspberry Pi 3 B+ has four built-in USB ports that provide enough connectivity for a mouse, keyboard or anything else that you feel the RPi needs. But if you want to add even more, you can still use a USB hub. Keep in mind, it is recommended that you use a powered hub so as not to overtax the onboard voltage regulator. Powering the Raspberry Pi 3 B+ is easy just plug and Play with 5V/2.5A USB power supply into the micro USB port. There’s no power button, so the RPi will begin to boot as soon as power is applied. To turn it off, simply shut down the Pi 3 B+, then remove power. The four built-in USB ports can even output up to 1.2A, enabling you to connect more power-hungry USB devices.

Key Features :

  1. Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
  2. 1GB LPDDR2 SDRAM
  3. 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
  4. Gigabit Ethernet over USB 2.0 (maximum throughput of 300 Mbps)
  5. Extended 40-pin GPIO header
  6. Full-size HDMI
  7. 4 USB 2.0 ports
  8. CSI camera port for connecting a Raspberry Pi camera
  9. DSI display port for connecting a Raspberry Pi touchscreen display
  10. 4-pole stereo output and composite video port
  11. Micro SD port for loading your operating system and storing data
  12. 5V/2.5A DC power input
  13. Power-over-Ethernet (PoE) support (requires separate PoE HAT)

  Technical Specification :

Model Raspberry Pi 3 Model B+
Processor Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
RAM 1GB LPDDR2
Connectivity Gigabit Ethernet over USB 2.0
Operating Power 5V/2.5A DC
GPIO Standard 40-pin GPIO Header
Video & Sound 2-Lane MIPI DSI Display Port
Clock Speed 1.4 GHz
On Board Ports 15-pin MIPI Camera Serial Interface (CSI-2), 4 x USB 2.0 Connector, 4-pole stereo output and composite video port, 40-pin 2.54 mm (2×20 strip) GPIO, Full-size HDMI Output Port
Micro-SD  Yes (FAT32 format), support maximum 32G Micro SD Card
Operating Temp (*C)  -10 to 60
Dimensions LxWxH 9 x 6 x 2 Centimeters

Package Include :

  • 1 x Raspberry Pi 3 Model B+
